Bose Panaray 502C Service Manual

21
ELECTRICAL PART LIST
502C Controller Main PCB Assembly
Resistors
Reference
Designator
Description Part Number Note
W1 0 Ohm Jumper, Chip 124896
W2 0 Ohm Jumper, Chip 124896
W3 0 Ohm Jumper, Chip 124896
W4 0 Ohm Jumper, Chip 124896
W5 0 Ohm Jumper, Chip 124896
W6 0 Ohm Jumper, Chip 124896
W7 0 Ohm Jumper, Chip 124896
W8 0 Ohm Jumper, Chip 124896
W9 0 Ohm Jumper, Chip 124896
W10 0 Ohm Jumper, Chip 124896
W11 0 Ohm Jumper, Chip 124896
W12 0 Ohm Jumper, Chip 124896
W13 0 Ohm Jumper, Chip 124896
R1 1K, 1/8W,1%, Chip 124894-1001
R2 1K, 1/4W, 52mm, MF, 1% 121245-2211001
R3 1K, 1/4W, 52mm, MF, 1% 121245-2211001
R4 1K, 1/8W,1%, Chip 124894-1001
R5 100K, 1/4W, 52mm, CF, 2% 121243-1211042
R6 100K, 1/4W, 52mm, CF, 2% 121243-1211042
R7 2K, 1/8W, 1%, Chip 124894-2001
R8 8.06K, 1/8W, 1%, Chip 124894-8061
R9 8.06K, 1/8W, 1%, Chip 124894-8061
R10 2K, 1/8W, 1%, Chip 124894-2001
R11 3.65K, 1/8W, 1%, Chip 124894-3651
R12 2K, 1/8W, 1%, Chip 124894-2001
R13 4.02K, 1/8W, 1%, Chip 124894-4021
R13 4.02K, 1/8W, 1%, Chip 124894-4021
R14 4.02K, 1/8W, 1%, Chip 124894-4021
R14 4.02K, 1/8W, 1%, Chip 124894-4021
R15 30.1K, 1/8W, 1%, Chip 124894-3012
R17 2K, 1/8W, 1%, Chip 124894-2001
R18 2.32K, 1/8W, 1%, Chip 124894-2321
R19 13K, 1/8W, 1%, Chip 124894-1302
R20 100K, 1/8W, 1%, Chip 124894-1003
R21 511 Ohm, 1/8W, 1%, Chip 124894-5110
R22 3.16K, 1/8W, 1%, Chip 124894-3161
R23 1.33K, 1/8W, 1%, Chip 124894-1331
R24 0 Ohm Jumper, Chip 124896
R25 274 Ohm, 1/8W, 1%, Chip 124894-2740
R26 274 Ohm, 1/8W, 1%, Chip 124894-2740
R27 18.2K, 1/8W, 1%, Chip 124894-1822
R28 8.66K, 1/8W, 1%, Chip 124894-8661
R29 6.34K, 1/8W, 1%, Chip 124894-6341
R30 2.21K, 1/8W, 1%, Chip 124894-2211
R31 1.91K, 1/8W, 1%, Chip 124894-1911
R32 43.2K, 1/8W, 1%, Chip 124894-4322
