15
502B Bass Box (see Figures 5 and 6)
MAIN PART LIST
Item
Number
Description Part Number Qty. Note
1 Cap, Top/Bottom, Gray
Ca
p
, To
p
/Bottom, White
182582-0P
294312
2
2 Bolt-Mounting 143580 8
3 Acoustic Foam 145705 3
4 Bracket, Structural 290979 4
5 Nut, Hex, Mach Screw, 7/16-14 290980-4414 8
6 Washer, Lock, Ext, Stl, Zinc Plate 108261-43 8
7 Screw, HIRS, 8-10x3/4, HEXW, Hex 293205-010 16
8 Safety, Hook 171556 2
9 Screw, 6-10x1/2,PAN,XRC/SQ 290294-08 4
10 Access Panel, Gray, XLR
Access Panel, White, XLR
Access Panel, Gray, Barrier
Access Panel, White, Barrier
Access Panel, 502 BEX, Black
Access Panel, Gray, Speakon
Access Panel, White, Speakon
142349-8RU
142349-9RU
142349-8SU
142349-9SU
142349-0CP
292035-001
292035-002
1
1
1
1
1
1
1
Non-RoHS
Non-RoHS
Non-RoHS
Non-RoHS
Non-RoHS
RoHS
RoHS
11 Fuse holder, Knob with O-Ring 149268 1
12 Fuse holder Body (includes nut) 149269 1
13 Washer, Neoprene 149270 1
14 Fuse, Standard Delay,7A 104715-700 1
15 Foam Tape 103068 4
16 Screw, Tapp, 4-16x1/2, (XLR)
Screw, HIRS, 8-10x3/4, (Barrier)
Screw, Tapp, 8-11x1, (Speakon)
145724-08
289388-16
290988-08
8
2
4
Non-RoHS
RoHS
RoHS
17 Connector , XLR, Dual
Connector, Barrier Strip, 4 pos.
Connector, Speakon
145717
148976-04
258213-002
2
1
2
Non-RoHS
RoHS
RoHS
18 Gasket, XLR Connector
Gasket, Barrier
Gasket, Speakon
146874
171243
252384
2
1
2
Non-RoHS
RoHS
RoHS
19 Fuse holder Nut 171731 1
20 Insert, Barbed, 10/32”x 20mm 145712-03 8
21 Screw, Mach, 10-32x 1-1½, PAN 291008-24 8
22 Woofer, 12”
(used with PC 003841, 019769, 004934,
004935, 004936, 007698 and 010744 only)
144392 1 Non-RoHS
Woofer, 12”
(used with PC 040090 and 040091 only)
291380-001 RoHS
23 Screw, Mach, 8-10 x 1, PAN, Gray
Screw, Mach, 8-10 x 1, PAN, White
289388-016
289388-016
12
12
*Product code 040090 (black) and 040091 (white) are a RoHS compliant version of
the 502B. Only RoHS compliant parts listed in the above chart can be used in the
502B with product code 040090 and 040091.
