Bose Panaray 502C Service Manual

50
502A WCB-5 U-Bracket Kit Parts List (see Figure 23)
Figure 23. WCB-5 U-Bracket Kit
ACCESSORY KIT PART LIST
Item
Number
Description Part Number Qty. Note
1 U-Bracket 148531 2 1
1 Bushing 148532 4 1
- Hardware Kit, Consists of: 173533 1
2 Locking Bracket 148536 2
3 Safety Cable 148506 2
4 Bolt, Button Head, 5mm, M8x12mm 148526-02 7
5 Bolt, Button Head, 5mm, M8x20mm 148526-10 5
6 Lock washer, M8 173450 11
7 Thumbscrew, M5x10mm 145750 3
8 Allen Wrench, 5mmx70mm 148544-1 1
- Poly bag, Hardware 173367 1 7
- Instruction Sheet 148537 1 1, 7
- Poly sleeve, U-Bracket 173365 2 1, 7
- Poly bag, Locking Bracket 173366 2 1, 7
- Carton, RSC 173368 1 1, 7
- Carton, Divider 173369 1 1, 7
1
2
3
4
5
6
6
7
8
