Bose Panaray 502C Service Manual

22
ELECTRICAL PART LIST
Resistors (continued)
502C Controller Main PCB Assembly
Reference
Designator
Description Part Number Note
R33 3.92K, 1/8W, 1%, Chip 124894-3921
R34 2.43K, 1/8W, 1%, Chip 124894-2431
R35 2K, 1/8W, 1%, Chip 124894-2001
R36 41.2K, 1/8W, 1%, Chip 124894-4122
R37 3.01K, 1/8W, 1%, Chip 124894-3011
R38 6.81K, 1/8W, 1%, Chip 124894-6811
R39 6.81K, 1/8W, 1%, Chip 124894-6811
R40 4.75K, 1/8W, 1%, Chip 124894-4751
R41 5.90K, 1/8W, 1%, Chip 124894-5901
R42 5.11K, 1/8W, 1%, Chip 124894-5111
R43 221K, 1/8W, 1%, Chip 124894-2213
R44 1.10K, 1/8W, 1%, Chip 124894-1101
R45 49.9K, 1/8W, 1%, Chip 124894-4992
R46 68.1K, 1/8W, 1%, Chip 124894-6812
R47 6.98K, 1/8W, 1%, Chip 124894-6981
R48 5.49K, 1/8W, 1%, Chip 124894-5491
R49 14K, 1/8W, 1%, Chip 124894-1402
R50 14K, 1/8W, 1%, Chip 124894-1402
R64 0 Ohm Jumper, Chip 124896
R65 1K, 1/8W,1%, Chip 124894-1001
R66 1K, 1/4W, 52mm, MF, 1% 121245-2211001
R67 1K, 1/4W, 52mm, MF, 1% 121245-2211001
R68 1K, 1/8W,1%, Chip 124894-1001
R69 2K, 1/8W, 1%, Chip 124894-2001
R70 8.06K, 1/8W, 1%, Chip 124894-8061
R71 8.06K, 1/8W, 1%, Chip 124894-8061
R72 2K, 1/8W, 1%, Chip 124894-2001
R73 3.65K, 1/8W, 1%, Chip 124894-3651
R74 2K, 1/8W, 1%, Chip 124894-2001
R75 4.02K, 1/8W, 1%, Chip 124894-4021
R75 4.02K, 1/8W, 1%, Chip 124894-4021
R76 4.02K, 1/8W, 1%, Chip 124894-4021
R77 30.1K, 1/8W, 1%, Chip 124894-3012
R79 2K, 1/8W, 1%, Chip 124894-2001
R80 2.32K, 1/8W, 1%, Chip 124894-2321
R81 13K, 1/8W, 1%, Chip 124894-1302
R82 100K, 1/8W, 1%, Chip 124894-1003
R83 511 Ohm, 1/8W, 1%, Chip 124894-5110
R84 3.16K, 1/8W, 1%, Chip 124894-3161
R85 1.33K, 1/8W, 1%, Chip 124894-1331
R86 0 Ohm Jumper, Chip 124896
R87 274 Ohm, 1/8W, 1%, Chip 124894-2740
R88 274 Ohm, 1/8W, 1%, Chip 124894-2740
R89 18.2K, 1/8W, 1%, Chip 124894-1822
R90 8.66K, 1/8W, 1%, Chip 124894-8661
R91 6.34K, 1/8W, 1%, Chip 124894-6341
