23
ELECTRICAL PART LIST
Resistors (continued)
502C Controller Main PCB Assembly
Reference
Designator
Description Part Number Note
R92 2.21K, 1/8W, 1%, Chip 124894-2211
R93 1.91K, 1/8W, 1%, Chip 124894-1911
R94 43.2K, 1/8W, 1%, Chip 124894-4322
R95 3.92K, 1/8W, 1%, Chip 124894-3921
R96 2.43K, 1/8W, 1%, Chip 124894-2431
R97 2K, 1/8W, 1%, Chip 124894-2001
R98 41.2K, 1/8W, 1%, Chip 124894-4122
R99 3.01K, 1/8W, 1%, Chip 124894-3011
R100 4.75K, 1/8W, 1%, Chip 124894-4751
R101 5.90K, 1/8W, 1%, Chip 124894-5901
R102 5.11K, 1/8W, 1%, Chip 124894-5111
R103 221K, 1/8W, 1%, Chip 124894-2213
R104 1.10K, 1/8W, 1%, Chip 124894-1101
R105 49.9K, 1/8W, 1%, Chip 124894-4992
R106 68.1K, 1/8W, 1%, Chip 124894-6812
R107 6.98K, 1/8W, 1%, Chip 124894-6981
R108 5.49K, 1/8W, 1%, Chip 124894-5491
R109 14K, 1/8W, 1%, Chip 124894-1402
R110 14K, 1/8W, 1%, Chip 124894-1402
R113 0 Ohm Jumper, Chip 124896
R117 0 Ohm Jumper, Chip 124896
R120 0 Ohm Jumper, Chip 124896
R125 0 Ohm Jumper, Chip 124896
R127 5.6K, 52mm, CF, 1/2W, 5% 121243-1515625
R128 100K, 1/4W, 52mm, CF, 2% 121243-1211042
R129 100K, 1/4W, 52mm, CF, 2% 121243-1211042
R130 4.75K, 1/8W, 1%, Chip 124894-4751
R131 4.75K, 1/8W, 1%, Chip 124894-4751
R132 4.75K, 1/8W, 1%, Chip 124894-4751
R133 2.43K, 1/8W, 1%, Chip 124894-2431
R134 4.75K, 1/8W, 1%, Chip 124894-4751
R135 4.75K, 1/8W, 1%, Chip 124894-4751
R136 4.75K, 1/8W, 1%, Chip 124894-4751
R137 2.43K, 1/8W, 1%, Chip 124894-2431
R138 4.75K, 1/8W, 1%, Chip 124894-4751
R139 4.75K, 1/8W, 1%, Chip 124894-4751
R140 4.75K, 1/8W, 1%, Chip 124894-4751
R141 2.43K, 1/8W, 1%, Chip 124894-2431
R142 4.75K, 1/8W, 1%, Chip 124894-4751
R143 4.75K, 1/8W, 1%, Chip 124894-4751
R144 4.75K, 1/8W, 1%, Chip 124894-4751
R145 2.43K, 1/8W, 1%, Chip 124894-2431
R146 47 Ohm, 1/4W, 52mm, CF, 2% 121243-1214702
R147 47 Ohm, 1/4W, 52mm, CF, 2% 121243-1214702
R148 47 Ohm, 1/4W, 52mm, CF, 2% 121243-1214702
R149 47 Ohm, 1/4W, 52mm, CF, 2% 121243-1214702
To Next Page
