ELECTRICAL PART LIST
Resistors (continued)
502C Controller Main PCB Assembly
Reference
Designator
Description Part Number Note
R150 47 Ohm, 1/4W, 52mm, CF, 2% 121243-1214702
R151 47 Ohm, 1/4W, 52mm, CF, 2% 121243-1214702
R152 47 Ohm, 1/4W, 52mm, CF, 2% 121243-1214702
R153 47 Ohm, 1/4W, 52mm, CF, 2% 121243-1214702
R154 4.75K, 1/8W, 1%, Chip 124894-4751
R155 4.75K, 1/8W, 1%, Chip 124894-4751
R156 0 Ohm Jumper, Chip 124896
R157 10K, 1/2W, 52mm, CF, 5% 121243-1511035
R158 47.5K, 1/8W, 1%, Chip 124894-4752
R159 47.5K, 1/8W, 1%, Chip 124894-4752
R160 1K, 1/8W,1%, Chip 124894-1001
R161 4.32K, 1/8W, 1%, Chip 124894-4321
R162 0 Ohm Jumper, Chip 124896
R166 20K, 1/8W, 1%, Chip 124894-2002
R167 1K, 1/8W,1%, Chip 124894-1001
R168 4.32K, 1/8W, 1%, Chip 124894-4321
R169 0 Ohm Jumper, Chip 124896
R173 20K, 1/8W, 1%, Chip 124894-2002
R174 681 Ohm, 1/8W, 1%, Chip 124894-6810
R175 681 Ohm, 1/8W, 1%, Chip 124894-6810
R176 681 Ohm, 1/8W, 1%, Chip 124894-6810
R177 681 Ohm, 1/8W, 1%, Chip 124894-6810
R180 221K, 1/8W, 1%, Chip 124894-2213
R182 0 Ohm Jumper, Chip 124896
R183 221K, 1/8W, 1%, Chip 124894-2213
R184 49.9K, 1/8W, 1%, Chip 124894-4992
R185 49.9K, 1/8W, 1%, Chip 124894-4992
R191 47.5 Ohm, 1/8W, 1%, Chip 124894-47R5
R192 47.5 Ohm, 1/8W, 1%, Chip 124894-47R5
R193 47 Ohm, 1/4W, 52mm, CF, 2% 121243-1214702
R194 47 Ohm, 1/4W, 52mm, CF, 2% 121243-1214702
R195 47.5 Ohm, 1/8W, 1%, Chip 124894-47R5
R196 47.5 Ohm, 1/8W, 1%, Chip 124894-47R5
R197 47.5 Ohm, 1/8W, 1%, Chip 124894-47R5
R198 47.5 Ohm, 1/8W, 1%, Chip 124894-47R5
R199 6.81K, 1/8W, 1%, Chip 124894-6811
R200 10K, 1/8W, 1%, Chip 124894-1002
R201 17.8K, 1/8W, 1%, Chip 124894-1782
R203 221 Ohm, 1/8W, 1%, Chip 124894-2210
R204 221 Ohm, 1/8W, 1%, Chip 124894-2210
R205 47.5K, 1/8W, 1%, Chip 124894-4752
R207 47.5K, 1/8W, 1%, Chip 124894-4752
R208 10K, 1/8W, 1%, Chip 124894-1002
R209 47.5K, 1/8W, 1%, Chip 124894-4752
R210 475 Ohm, 1/8W, 1%, Chip 124894-4750
R212 4.75K, 1/8W, 1%, Chip 124894-4751
