Bose Panaray 502C Service Manual

25
Capacitors
ELECTRICAL PART LIST
502C Controller Main PCB Assembly
Reference
Designator
Description Part Number Note
C1 1000pF, 10%, Chip 124956-1022
C2 1000pF, 10%, Chip 124956-1022
C3 22µF, 35V, Electrolytic 119944-220
C4 22µF, 35V, Electrolytic 119944-220
C5 0.1µF, +80/-20%, Chip 124959-104
C6 0.1µF, +80/-20%, Chip 124959-104
C7 100pF, 5%, Chip 124956-1012
C8 100pF, 5%, Chip 124956-1012
C9 .01µF, 5%, Film 137127-103
C10 680pF, 10%, Ceramic 137269-681
C11 .01µF, 5%, Film 137127-103
C12 0.0047µF, 5%, Film 137127-472
C13 0.0047µF, 5%, Film 137127-472
C14 .01µF, 5%, Film 137127-103
C15 .01µF, 5%, Film 137127-103
C16 0.1µF, +80/-20%, Chip 124959-104
C17 0.1µF, +80/-20%, Chip 124959-104
C18 .1µF, 5%, Film 137127-104
C19 .047µF, 5%, Film 137127-473
C20 .1µF, 5%, Film 137127-104
C21 100pF, 5%, Chip 124956-1012
C22 .1µF, 5%, Film 137127-104
C23 .1µF, 5%, Film 137127-104
C24 .47µF, 5%, Film 137127-474
C25 .1µF, 5%, Film 137127-104
C26 .1µF, 5%, Film 137127-104
C27 .47µF, 5%, Film 137127-474
C28 .47µF, 5%, Film 137127-474
C29 .22µF, 5%, Film 137127-224
C30 .22µF, 5%, Film 137127-224
C31 .1µF, 5%, Film 137127-104
C32 .1µF, 5%, Film 137127-104
C33 .22µF, 5%, Film 137127-224
C34 .022µF, 5%, Film 137127-223
C35 .18µF, 5%, Film 137127-184
C36 0.1µF, +80/-20%, Chip 124959-104
C37 0.1µF, +80/-20%, Chip 124959-104
C47 1000pF, 10%, Chip 124956-1022
C48 1000pF, 10%, Chip 124956-1022
C49 22µF, 35V, Electrolytic 119944-220
C50 22µF, 35V, Electrolytic 119944-220
C51 0.1µF, +80/-20%, Chip 124959-104
C52 0.1µF, +80/-20%, Chip 124959-104
C55 100pF, 5%, Chip 124956-1012
C56 100pF, 5%, Chip 124956-1012
C57 .01µF, 5%, Film 137127-103
