Bose Panaray 502C Service Manual

27
Capacitors (continued)
ELECTRICAL PART LIST
502C Controller Main PCB Assembly
Reference
Designator
Description Part Number Note
C109 .0047µF,20%,Metallized Paper,
(Euro/UK/Aus/Japan)
146354 5
C110 10,000pF, +80/-20%, Chip 124959-103
C111 10,000pF, +80/-20%, Chip 124959-103
C112 10,000pF, +80/-20%, Chip 124959-103
C113 2200µF, 50V, 105C, Electrolytic, 20% 144000-222H 5
C114 2200µF, 50V, 105C, Electrolytic, 20% 144000-222H 5
C115 1µF, 50V, Electrolytic 137265-1R0
C116 1µF, 50V, Electrolytic 137265-1R0
C117 1µF, 50V, Electrolytic 137265-1R0
C118 1µF, 50V, Electrolytic 137265-1R0
C119 100pF, 5%, Chip 124956-1012
C120 100pF, 5%, Chip 124956-1012
C129 0.1µF, +80/-20%, Chip 124959-104
C130 0.1µF, +80/-20%, Chip 124959-104
C131 0.1µF, +80/-20%, Chip 124959-104
C132 0.1µF, +80/-20%, Chip 124959-104
C133 10,000pF, +80/-20%, Chip 124959-103
C142 1000pF, 10%, Chip 124956-1022
C143 1000pF, 10%, Chip 124956-1022
C144 1000pF, 10%, Chip 124956-1022
C145 1000pF, 10%, Chip 124956-1022
C146 1000pF, 10%, Chip 124956-1022
C147 1000pF, 10%, Chip 124956-1022
C148 1000pF, 10%, Chip 124956-1022
C149 1000pF, 10%, Chip 124956-1022
C150 0.1µF, +80/-20%, Chip 124959-104
C151 0.1µF, +80/-20%, Chip 124959-104
C152 22µF, Bi-polar, Electrolytic, 20% 147522-220
C153 22µF, 35V, Electrolytic 119944-220
C154 22µF, 35V, Electrolytic 119944-220
C155 22µF, 35V, Electrolytic 119944-220
C156 22µF, 35V, Electrolytic 119944-220
C157 22µF, 35V, Electrolytic 119944-220
C158 22µF, 35V, Electrolytic 119944-220
C159 22µF, 35V, Electrolytic 119944-220
C160 22µF, 35V, Electrolytic 119944-220
C161 0.1µF, +80/-20%, Chip 124959-104
C162 100pF, 5%, Chip 124956-1012
C163 100pF, 5%, Chip 124956-1012
C164 100pF, 5%, Chip 124956-1012
