Connectors
ELECTRICAL PART LIST
502C Controller Main PCB Assembly
Reference
Designator
Description Part Number Note
J1 Harness Assy, Quick Disconnect 143968 5
J2 Harness Assy, Quick Disconnect 143968 5
J3 XLR, Female (Euro/Japan/UK/Aus) 189222-001
J4 XLR, Female (Euro/Japan/UK/Aus) 189222-001
P1 Header, 2 pin 143963
P2 Header, 2 pin 143963
P3 Header 143965
P4 Header, 12 pin 170250
P5 Header, 12 pin 170250
P6 Header, 6 pin (US/Can.) 143974
P7 Header, 6 pin (US/Can.) 143974
P8 Header, 6 pin (US/Can.) 143974
P9 XLR, Male (Euro/Japan/UK/Aus) 144004
P10 XLR, Male (Euro/Japan/UK/Aus) 144004
P11 XLR, Male (Euro/Japan/UK/Aus) 144004
P12 XLR, Male (Euro/Japan/UK/Aus) 144004
