Bose Panaray 502C Service Manual

61
Figure 36. High Frequency EQ
Frequency in Hz
20 200 2K 20K
-40
-30
-20
-10
0
10
20
30
Gain
in dB
Output is measured from U4 pins 1 and 14. 502C controls set as in Figure 26 except:
Mode switch is set to 1 (Full Range Mode).
