22
Appendix
Main Specications
Sampling Frequency 44.1 kHz
AD/DA Conversion 32 bits
Processing 32-bit oating point
Recording/Playback
Number of Tracks: 1
Data Format: WAV (44.1 kHz, 32-bit oat, stereo)
Maximum Recording Time: Approx. 1.5 hours (1 track), Approx.13 hours (total of All memories)
Rhythm Type 57 Patterns x 2 Variations
Rhythm Kit 7 types
Eect Reverb (only for rhythm part)
Memory 99
Nominal Input Level INPUT A/MONO, B: -20 dBu
Input Impedance INPUT A/MONO, B: 1 MΩ
Nominal Output Level OUTPUT A/MONO, B:-20 dBu
Output Impedance OUTPUT A/MONO, B: 1 kΩ
Recommended Load Impedance OUTPUT A/MONO, B: 10 kΩ or greater
Bypass Buered bypass
Display Graphic LCD (96 x 32 dots, RGB backlit LCD)
Connectors
NPUT A/MONO, B jacks: 1/4-inch phone type
OUTPUT A/MONO, B jacks: 1/4-inch phone type
STOP/MEMORY jack: 1/4-inch TRS phone type
USB port: USB B type
MIDI (IN, OUT) jacks: stereo miniature type
DC IN jack
Power Supply
Alkaline battery (9 V, 6LR61 or 6LF22)
AC adaptor (PSA series: sold separately)
Current Draw 170 mA
Expected battery life under
continuous use
These gures will vary depending on the actual conditions of use.
Alkaline: Approx. 2 hours
Dimensions
73 (W) x 129 (D) x 56 (H) mm
2-7/8 (W) x 5-1/8 (D) x 2-1/4 (H) inches
Weight
(excluding battery)
405 g/15 oz
(including battery)
450 g/1 lb
Accessories
Owner’s Manual
Leaet (“USING THE UNIT SAFELY,” “IMPORTANT NOTES,” and “Information”)
Alkaline battery (9 V, 6LR61 or 6LF22)
Options (sold separately)
AC adaptor: PSA-S series
Footswitch: FS-5U
Dual Footswitch: FS-6, FS-7
Expression Pedal: FV-500H, FV-500L, EV-30, Roland EV-5
TRS/MIDI connecting cable: BMIDI-5-35
* 0 dBu = 0.775 Vrms
* This document explains the specications of the product at the time that the document was issued. For the latest information, refer to the
Roland website.
