Main Specifications
20
Main Specifications
* AF method (Adaptive Focus method) This is a proprietary method from Roland
& BOSS that vastly improves the signal-to-noise (SN) ratio of the AD and DA
converters.
INPUT A (MONO), INPUT B: -20 dBu
INPUT A (MONO), INPUT B: +7 dBu
INPUT A (MONO), INPUT B: 1 MΩ
OUTPUT A (MONO), OUTPUT B: -20 dBu
OUTPUT A (MONO), OUTPUT B: +7 dBu
OUTPUT A (MONO), OUTPUT B: 1 kΩ
Recommended Load Impedance
OUTPUT A (MONO), OUTPUT B: 10 kΩ or greater
[FEEDBACK] knob
[LEVEL] knob
[DEPTH] knob
[RATE] knob
[HI CUT] knob
[OFFSET] Knob
Pedal switch
CHECK indicator (Used for indication of Tempo and check battery)
INPUT A (MONO) jack, INPUT B jack, OUTPUT A (MONO) jack, OUTPUT B jack: 1/4-
inch phone type
CTL/EXP jack: 1/4-inch TRS phone type
DC IN jack
MIDI IN jack: Stereo miniature phone type
Alkaline battery (9 V, 6LR61 or 6LF22, commercially available)
AC adaptor (PSA series: sold separately)
Expected battery life under
continuous use
(These figures will vary depending on
the actual conditions of use.)
Alkaline: Approx. 4.5 hours
73 (W) x 129 (D) x 59 (H) mm
2-7/8 (W) x 5-1/8 (D) x 2-3/8 (H) inches
Weight (including battery)
Leaflet (“USING THE UNIT SAFELY”, “IMPORTANT NOTES”, and “Information”)
Dry battery (9 V, 6LR61 or 6LF22)
Options (sold separately)
Footswitch: FS-5U
Dual footswitch: FS-6, FS-7
Expression pedal: FV-500H, FV-500L, EV-30, Roland EV-5
TRS/MIDI connecting cable: BMIDI-5-35, BMIDI-1-35, BMIDI-2-35, BCC-1-3535, BCC-2-
* 0 dBu＝0.775 Vrms
* This document explains the specifications of the product at the time that the document was issued. For the latest
information, refer to the Roland website.
