Bowflex Xtreme - Get to Know Your Machine

2
Left Pulley
Arm
5 0" Bent Lat Bar
Lat Cross Bar
Upper Lat
Tower
Rod Box
w/ Rods
Squat Bar
Seat Back Pad
Squat Straps
Seat Backbone
Seat Bottom
Right Pulley
Arm
LowerLat
Tower
Rear Cross
Member
Left Frame
Rail
Wrapped
Slider Pulley
w/ Cable
Right Frame Rail
Base Frame
Platform
Squat Pulley
Frame
Foam Roll e r
3 / 4" End Cap
3 / 4" C h rom e
Tu b e
Leg Extension
B a ck b on e
If you ordered the optional Leg Extension
Attachment, you will receive the parts shown to the
left.
Leg Extension - Optional Attachment
Get To Know
Your Machine
