Bradco SG30 - Stump Grinder Assembly (Continued)

STUMP GRINDER ASSEMBLY
9694 8-1-14-3
ITEM REQ’D PART NO. DESCRIPTION
1 2 1022 .31” UNC X 1.00” Hex Capscrew
2 4 1513 .31” Flat Washer
3 2 1502 .31” Lock Washer
4 2 1225 .31” UNC Hex Nut
5 7 1953 .38” UNC X .75” Flange Head Capscrew
6 2 100769 Pin - 1.00” X 2.50”
7 1 101245 Cylinder Assembly - Lift
- 45617 Replacement Seal Kit
8 1 25453 Manual Tube
9 1 100770 Pin - 1.00” X 4.00”
10 2 1051 .38” UNC X 3.00” Hex Capscrew
2 1837 .38” UNC Deformed Lock Nut
11 1 100379 Pin - 1.25” X 13.50”
12 1 100322 Yoke
13 1 100378 Pin - 1.25” X 11.38”
14 1 100420 Valve Cover
15 1 100321 Mounting Bracket
16 1 31990 Pin - 1.00” X 4.50”
17 1 100324 Cylinder Assembly - Swing
- 45617 Replacement Seal Kit
18 2 6616 Grease Fitting
19 1 100323 Stump Grinder Frame
20 2 1043 .38” UNC X 1.00” Hex Capscrew
2 1837 .38” UNC Deformed Lock Nut
21 1 105762 Access Cover
22 2 1939 .25” UNC X .75” Flangehead Hex Capscrew
23 1 101802 Brace Stand
24 2 1044 .38” UNC X 1.25” Hex Capscrew
2 1837 .38” UNC Deformed Lock Nut
ASSEMBLY #100318
75578
35
