INSTALLATION
9772 7-29-14-2
GENERAL INFORMATION
The following instructions will help you mount your stump grinder onto your skid steer
loader. The stump grinder uses the quick-attach system for ease of installation.
Remember to read all safety warning, decals and operation instructions before operat-
ing the attachment. If there is any portion of this manual that you do not understand, contact
your dealer.
WARNING! OPERATING THE STANDARD FLOW STUMP GRINDER ON A HIGH FLOW
HYDRAULIC SYSTEM MAY CAUSE SEVERE INJURY OR DEATH TO THE
OPERATOR OR BYSTANDERS DUE TO THE INCREASED RPM.
INSTALLATION INSTRUCTIONS
1. Remove shipping banding.
2. Remove any existing attachment from the loader.
3. Following all standard safety practices and the instructions for installing an attachment
in your skid steer operator's manual, install the stump grinder onto your skid steer.
NOTE: IT IS IMPORTANT TO MAKE SURE THE LOCKING MECHANISM ON YOUR QUICK
ATTACH IS ENGAGED, THEREFORE LOCKING THE ATTACHMENT ONTO THE SKID
STEER
4. Lower the unit to the ground and remove the key.
5. If the guard assembly was not installed at the factory, install it now using the hardware
provided. (See Parts Section for hardware locations.)
6. Ifinstallingthehighowstumpgrinder,connectthecasedraincouplertothecasedrain
on your skid steer loader.
7. Relieve pressure from the auxiliary hydraulic system. Connect couplers to the auxil-
iary hydraulic system of your skid steer loader. Route the hoses in such a fashion as to
avoidpinchingorchang.
CAUTION! BE SURE CASE DRAIN COUPLER IS COMPLETELY ENGAGED. IMMEDIATE
HYDRAULIC MOTOR SEAL FAILURE WILL OCCUR IF CASE DRAIN IS NOT
SUCCESSFULLY CONNECTED.
