Bradco SG30 - Hydraulic Valve Assembly (Continued)

HYDRAULIC VALVE ASSEMBLY
9700 8-1-14-2
ITEM REQ’D PART NO. DESCRIPTION
1 6 3434 90° Elbow 6MBo-6MJ
2 1 38196 Hose .25” X 38” 6FJX-6FJX 45°
3 1 38197 Hose .25” X 29” 6FJX-6FJX 45°
4 2 30140 90° Elbow 6MBo-6MJ - XL
5 1 38195 Hose .25” X 19” 6FJX-6FJX
6 1 37345 Hose .25” X 28” 6FJX-6FJX
7 1 101395 Control Valve
8 2 30347 90° Elbow 12MBo-12MJ - L
9 3 1514 .38” Flat Washer
10 3 1503 .38” Lock Washer
11 3 1043 .38” UNC X 1.00” Hex Capscrew
12 2 3419 Straight Connector 12MBo-12MJ
ASSEMBLY #100982
75578
43
