9702 8-1-14-3
ITEM REQ’D PART NO. DESCRIPTION
1 2 38232 Hose .62” X 52” 10MBo 90° - 12FJX
2 1 17787 Hydraulic Motor
** 45814 Replacement Seal Kit
3 4 1841 .50” UNC Deformed Lock Nut
4 1 100860 Motor Mount
5 2 1091 .50” UNC X 1.75” Hex Capscrew
6 2 6886 Rubber Bumper
7 1 17808 Coupler
8 4 1799 .38” UNC X 1.50” Sockethead Capscrew
9 1 22277 Roll Pin
10 1 100988 Right Angle Gearbox Assembly
- 19701 Replacement Castle Nut
- 19702 Replacement Input Seal
- 19703 Replacement Output Seal
- 7781 Replacement Breather Plug
11 4 1839 .62” UNC Deformed Oval Lock Nut
12 8 1627 .62” Hard Flat Washer
13 4 10071 .62” UNC X 2.25” Hex Capscrew - Grade 8
14 1 1613 Cotter Pin
STANDARD FLOW DRIVE ASSEMBLY
ASSEMBLY #100415
** Field replacement of the internal motor seals voids warranty.
