9704 8-1-14-4
ITEM REQ’D PART NO. DESCRIPTION
1 2 38233 Hose .75” X 52” 12FJX - 12FJX
2 1 22600 90° Elbow 12MBo-12MJ
3 1 30292 Straight Connector 16MBo-12FB
4 1 30051 90° Elbow 16MBo-12MJ
5 1 37482 Case Drain Hose .25” X 132” 6FJX-6FJX
1 38234 Case Drain Hose .25” X 148” 6FJX-6FJX
(Not Included in Drive Assembly)
6 1 3269 Straight Adapter 8MBo-6MJ
(Not Included in Drive Assembly)
7 1 84923 Male Coupler
(Not Included in Drive Assembly)
8 1 101793 Hydraulic Motor
** 45898 Replacement Shaft Seal Kit
** 45899 Replacement Rear Seal Kit
9 8 1841 .50” UNC Deformed Lock Nut
10 1 30388 45° Elbow 4MBo-6MJ
11 4 6886 Rubber Bumper
12 2 101785 Motor Mount
13 4 10086 .50” UNC X 2.25” Capscrew
14 4 1799 .38” UNC X 1.50” Sockethead Capscrew
15 1 100917 Coupler
16 1 22277 Roll Pin
17 1 101509 Right Angle Gearbox Assembly
- 19701 Replacement Castle Nut
- 102011 Replacement Input Seal
- 102010 Replacement Output Seal
- 7781 Replacement Breather Plug
18 4 1936 .75” UNC Deformed Oval Lock Nut
19 8 1649 .75” Hard Flat Washer
20 4 1140 .75” UNC X 2.25” Hex Capscrew
21 1 1613 Cotter Pin
HIGH FLOW DRIVE ASSEMBLY
ASSEMBLY #100417
** Field replacement of the internal motor seals voids warranty.
