6.0 Process Flow and Wiring Tables
Each Process Flow diagram has a wiring table associated with setting up the connections to DB-9 on the
rear of the actuator, and HD-44 which is the User I/O connector on the rear of the power supply. One excep-
tion to this is “For Use with a Custom Actuator” Process Flow 10, which has no wiring table associated with
it.
Process Flow 6 additionally has Preset Switching Diagrams, PLC Wiring Table, and an Exter-
nal Preset Select Binary Table.
