Automation Guide Process Flow and Wiring Tables
100-214-273 Rev. 1 13
6.2.1 Wiring Table, Actuator, External Preset Select Process Flow 2
#2 Process Flowchart 2
Base/Start connector on
actuator rear DB-9
Step Signal Name Pin Colors Direction- Signal Type Definition
1 PB2 RETURN 1 Black Input 24V True PB (actuator start) input
2 PB1 RETURN 2 White Input 24V True PB (actuator start) input
3 E-STOP RETURN 3 Red Input 24V True E-STOP input
4 E-STOP RETURN 4 Green Input 24V True E-STOP input
J3 User I/O connector on
power supply rear HD-44
Signal Name Pin # Colors Direction Signal Type Definition
5 EXT_RESE
Blk/Wht/Orn +24V +24V Source
15 User definable input 31 Wht/Red/Blu Input 24V True Set:SELECT PRESET#16
16 User definable input 32 Blk/Grn/Wht Input 24V True Set:SELECT PRESET#1
17 User definable input 33 Wht/Blk/Grn Input 24V True Set:SELECT PRESET#2
18 PB RELEASE 34 Red/Wht/Grn Output 0V True PB Release
19 24V RETURN 41 Grn/Orn/Red 24V Return 24V Return
20 24V SOURCE 42 Orn/Red/Blu +24V +24V Source
NOTE
i
All voltages shown in this manual are direct current (DC) unless otherwise noted
