Process Flow and Wiring Tables

18 100-214-273 Rev. 1

6.4.1 Wiring Table, Actuator, Sonics Disabled, Process Flow 4

#4 Process Flowchart 4

Base/Start connector on

actuator rear DB-9

Step Signal Name Pin Colors Direction- Signal Type Definition

1 PB2 RETURN 1 Black Input 24V True PB (actuator start) input

2 PB1 RETURN 2 White Input 24V True PB (actuator start) input

3 E-STOP RETURN 3 Red Input 24V True E-STOP input

4 E-STOP RETURN 4 Green Input 24V True E-STOP input

J3 User I/O connector on

power supply rear HD-44

Signal Name Pin # Colors Direction Signal Type Definition

5 User definable input 1 Wht/Blk Input 24V True Set: SONICS DISABLE

5 EXT_RESET 3 Grn/Blk Input 24V True System Reset

6 G_ALARM 6 Blk/Wht Output 0V True General Alarm

7 24V RETURN 12 Orn/Red 24V Return 24V Return

8 24V SOURCE 13 Blu/Red Output +24V Source +24V Source

9 READY 21 Blu/Blk/Wht Output 0V True Ready Output

10 24V RETURN 27 Blu/Wht/Orn 24V Return 24V Return

11 24V SOURCE 28 Blk/Wht/Orn +24V +24V Source

12 PB RELEASE 34 Red/Wht/Grn Output 0V True PB Release

13 24V RETURN 41 Grn/Orn/Red 24V Return 24V Return

14 24V SOURCE 42 Orn/Red/Blu +24V +24V Source

NOTE

All voltages shown in this manual are direct current (DC) unless otherwise noted
