6.6.4 External Preset Select Binary Table
User I/O Input Pins When using External Preset Select
User I/O Input Pin #
31 17 19 33 32
PRESET
(16) (8) (4) (2) (1)
PRESET
1 OFF OFF OFF OFF ON 1
2 OFF OFF OFF ON OFF 2
3 OFF OFF OFF ON ON 3
4 OFF OFF ON OFF OFF 4
5 OFF OFF ON OFF ON 5
6 OFF OFF ON ON OFF 6
7 OFF OFF ON ON ON 7
8 OFF ON OFF OFF OFF 8
9 OFF ON OFF OFF ON 9
10 OFF ON OFF ON OFF 10
11 OFF ON OFF ON ON 11
12 OFF ON ON OFF OFF 12
13 OFF ON ON OFF ON 13
14 OFF ON ON ON OFF 14
15 OFF ON ON ON ON 15
16 ON OFF OFF OFF OFF 16
(16) (8) (4) (2) (1)
31 17
19 33 32
