Process Flow and Wiring Tables
20 100-214-273 Rev. 1
6.5.1 Wiring Table, Actuator, Sonics Disabled and Presets, Process Flow 5
#5 Process Flowchart 5
Base/Start connector on
actuator rear DB-9
Step Signal Name Pin Colors Direction- Signal Type Definition
1 PB2 RETURN 1 Black Input 24V True PB (actuator start) input
2 PB1 RETURN 2 White Input 24V True PB (actuator start) input
3 E-STOP RETURN 3 Red Input 24V True E-STOP input
4 E-STOP RETURN 4 Green Input 24V True E-STOP input
J3 User I/O connector on
power supply rear HD-44
Signal Name Pin # Colors Direction Signal Type Definition
5 User definable input 1 Wht/Blk Input 24V True Set:EXT SONICS DISABLE
6 EXT_RESET 3 Grn/Blk Input 24V True System Reset
7 G_ALARM 6 Blk/Wht Output 0V True General Alarm
8 User definable output 8 Grn/Wht Output 24V True Set: Confirm Preset
9 24V RETURN 12 Orn/Red 24V Return 24V Return
10 24V SOURCE 13 Blu/Red Output +24V Source +24V Source
11 User definable input 17 Wht/Blk/Red Input 24V True Set:SELECT PRESET #8
12 User definable input 19 Grn/Blk/Wht
13 READY 21 Blu/Blk/Wht Output 0V True Ready Output
14 24V RETURN 27 Blu/Wht/Orn 24V Return 24V Return
15 24V SOURCE 28 Blk/Wht/Orn +24V +24V Source
16 User definable input 31 Wht/Red/Blu Input 24V True Set:SELECT PRESET#16
17 User definable input 32 Blk/Grn/Wht Input 24V True Set:SELECT PRESET#1
18
User definable input 33 Wht/Blk/Grn Input 24V True Set:SELECT PRESET#2
19 PB RELEASE 34 Red/Wht/Grn Output 0V True PB Release
20 User definable output 36 Orn/Red/Grn Output 24V True Set:NOTE
21 24V RETURN 41 Grn/Orn/Red 24V Return 24V Return
22 24V SOURCE 42 Orn/Red/Blu +24V +24V Source
All voltages shown in this manual are direct current (DC) unless otherwise noted
