6.6.3 Wiring Table, Process Flow 6, PLC Connections
Pin Definition, DB9, Actuator
1 PB (actuator start) input
2 PB (actuator start) input
6 Source 24VDC (for hard contact)
7 Source 24VDC (for hard contact)
8 Source 24VDC (for hard contact)
9 Source 24VDC (for hard contact)
3 E-STOP input
4 E-STOP input
Definition, J3, Power Supply Pin Definition, cont´d
• 1 • Set: EXT SONICS DELAY 23 10VDC reference voltage from PS
2 Cycle Abort 24 Amplitude signal from PS
3 System Reset 25 User Frequency offset control signal
4 SV1 Source 26 Run signal from PS
5 Reject Alarm 27 24VDC Return
6 General Alarm 28 +24VDC Source
7 Actuator return signal 29 General Alarm Relay
• 8 • AVAILABLE 30 Weld On Relay
9 Memory Signal P/S • 31 • Set: SELECT PRESET #16
10 User Amplitude control signal • 32 • Set: SELECT PRESET #1
11 Memory Clear signal to PS • 33 • Set: SELECT PRESET #2
12 24VDC Return 34 PB Release
13 +24VDC Source 35 Weld On
14 Relay Contact Output 1 • 36 • AVAILABLE
15 Relay Contact Output 2 37 Power Signal from PS
16 SV1 Return 38 Frequency Signal from PS
• 17 • Set: SELECT PRESET #8 39 Seek Signal from PS
18 External Seek Input 40 Store Signal from PS
• 19 • Set: SELECT PRESET #4 41 24V Return
20 Suspect Part Alarm 42 +24V Source
21 Ready Output 43 Relay Contact Output
•22 •AVAILABLE 44 Relay Contact Output
