Branson 2000 series - 1-Wiring Table, Actuator Delayed Horn Travel, Process Flow 7

Automation Guide Process Flow and Wiring Tables
100-214-273 Rev. 1 31
6.7.1 Wiring Table, Actuator Delayed Horn Travel, Process Flow 7
#7 Process Flowchart 7
Base/Start connector on
actuator rear DB-9
Step Signal Name Pin Colors Direction- Signal Type Definition
1 PB2 RETURN 1 Black Input 24V True PB (actuator start) input
2 PB1 RETURN 2 White Input 24V True PB (actuator start) input
3 E-STOP RETURN 3 Red Input 24V True E-STOP input
4 E-STOP RETURN 4 Green Input 24V True E-STOP input
J3 User I/O connector on
power supply rear HD-44
Signal Name Pin # Colors Direction Signal Type Definition
5 User definable input 1 Wht/Blk Input 24V True Set:EXTERNAL START
6 EXT_RESET 3 Grn/Blk Input 24V True System Reset
7 G_ALARM 6 Blk/Wht Output 0V True General Alarm
8 User definable output 8 Grn/Wht Output 24V True Set: EXTERNAL START
9 24V RETURN 12 Orn/Red 24V Return 24V Return
10 24V SOURCE 13 Blu/Red Output +24V Source +24V Source
11 READY 21 Blu/Blk/Wht Output 0V True Ready Output
12 24V RETURN 27 Blu/Wht/Orn 24V Return 24V Return
13 24V SOURCE 28 Blk/Wht/Orn +24V +24V Source
14 PB RELEASE 34 Red/Wht/Grn Output 0V True PB Release
15 24V RETURN 41 Grn/Orn/Red 24V Return 24V Return
16 24V SOURCE 42 Orn/Red/Blu +24V +24V Source
NOTE
i
All voltages shown in this manual are direct current (DC) unless otherwise noted
