Process Flow and Wiring Tables
40 100-214-273 Rev. 1
6.12.1 Wiring Table, Converter Stack, External Preset Select, Process Flow 12
#11 Process Flowchart 12
Install 100-246-1178
jumper box into J7
J3 User I/O connector on
power supply rear HD-44
Signal Name Pin # Colors Direction Signal Type Definition
1 User definable input 1 Wht/Blk Input 24V True Set:EXT SIGNAL
2 EXT_RESET 3 Grn/Blk Input 24V True System Reset
3 G_ALARM 6 Blk/Wht Output 0V True General Alarm
4 User definable output 8 Grn/Wht Output 24V True Set:Confirm Preset
5 24V RETURN 12 Orn/Red 24V Return 24V Return
6 24V SOURCE 13 Blu/Red Output +24V Source +24V Source
7 User definable input 17 Wht/Blk/Red Input 24V True Set:SELECT PRESET #8
8 User definable input 19 Grn/Blk/Wht Input 24V True Set:SELECT PRESET #4
9 READY 21 Blu/Blk/Wht Output 0V True Ready Output
10 24V RETURN 27 Blu/Wht/Orn 24V Return 24V Return
11 24V SOURCE 28 Blk/Wht/Orn +24V +24V Source
12 User definable input 31 Wht/Red/Blu Input 24V True Set:SELECT PRESET
13 User definable input 32 Blk/Grn/Wht Input 24V True Set:SELECT PRESET #1
14 User definable input 33 Wht/Blk/Grn Input 24V True Set:SELECT PRESET #2
15 PB RELEASE 34 Red/Wht/Grn Output 0V True PB Release
16 24V RETURN 41 Grn/Orn/Red 24V Return 24V Return
17 24V SOURCE 42 Orn/Red/Blu +24V +24V Source
NOTE
i
All voltages shown in this manual are direct current (DC) unless otherwise noted
