J3 Input Pins Default setting Selectable Setting (any pin)
J3-1 Ext Signal Ext Sonics Delay
J3-17 Select Preset #8 Display Lock Ext Signal
J3-19 Select Preset #4 Sonics Disable Memory Reset
J3-31 Display Lock
Sync In Ext Start (input)
J3-32 Select Preset #1 Select Preset #16 (pin 31 only)
J3-33 Select Preset #2
J3 Output Pins Default Setting Selectable Setting (any pin)
J3-8 Disabled
J3-22 Disabled
Cycle Okay Overload Alarm
J3-36 Disabled Confirm Preset Modified Alarm
External Beeper Note
No Cycle Alarm Ext Start (output)
Missing Part Sync Out
Automation Guide Special Features in V9.xx Firmware
100-214-273 Rev. 1 3
Note: Regardless of current settings, by choosing factory
default setting in Menu, you will restore factory
settings.
All voltages shown in this manual are direct current (DC) unless otherwise noted.
Signal Definitions (Refer to Section 8.0, Glossary for Version 9 for additional definitions.)
Confirm Preset: A user output signal that will indicate that a weld cycle preset # has been input from the
external controller.
Cycle Okay: A user output signal that indicates no detectable alarm conditions occurred during the last weld
cycle.
External Beeper: An output pin that operates the same as the internal beeper, and could operate an external
(louder) device or light.
