135
PERIODIC MAINTENANCE & ADJUSTMENT
10. TOE-IN
Checking
If the toe-in is not properly aligned, the steering wheel
may be uncontrollable or the tractor may produce an ab-
normal vibration. Measure the distance A and the dis-
tance B of the front wheels and see if the different be-
tween the two measurements is 0.16 ~ 0.3 in[4-8mm].
Adjusting
If not, loosen nuts at the end of the cylinder rod on both
sides and adjust the length of the screws. Tighten the
nuts when the toe-in is 0.16 ~ 0.3 in[4-8mm].
• Left and right adjustment of screw length must be same.
To Next Page
