65
5) PRE-HEAT LAMP
Lamp will come on when the ignition switch is put into the
“ON” position with outside temperature of around 40°F,
indicating that electricity is supplied to the heater or glow
plugs. Turn the ignition switch to “START” after the lamp
has been turned off (it is turned off automatically) then it
will start the engine.
Note) The length of time the thermostat stays on will de-
pend on the temperature of the engine coolant.
Coolant temp : 32°F ~ 60°F 10sec
32°F ~ 5°F 20sec
6) BATTERY CHARGING LAMP
It will be turned on when the key switch is put into the “ON”
position, and will be turned off when the battery starts being
charged after engine is started and the engine revolution in-
creases. The battery will not be charged with the engine below
1,000 rpm. (The rpm should be 1,500 rpm or higher)
7) ENGINE OIL PRESSURE LAMP
Lamp will come on when the ignition switch is put into the “ON”
position. It will turn off when the engine is started.
If this lamp comes on while the engine is running, it indicates a
problem in the engine oil system. Stop the engine immediately
and check for problems.
FUNCTIONS
