64
FUNCTIONS
1) ENGINE RPM INDICATOR
The needle indicates the number of engine RPM
2) ENGINE HOUR METER
It indicates the tractor’s running hours. By multiplying the digit
in the far right position by 6, you will get the time in minute.
3) PTO WORK
It indicates the position where PTO achieves 540rpm when en-
gine rpm is 2600rpm at PTO 1st stage.
It indicates the position where PTO achieves 1000rpm when
engine rpm is 2600rpm or where PTO achieves 540rpm when
engine rpm is 1000rpm at PTO 2nd stage.(econo-position).
4) PTO LAMP
Lamp will come on when PTO is engaged. On the contrary, if
PTO is disengaged, lamp will be turned off.
20R OPERATORS MANUAL (030712).indd 64 3/8/2012 4:04:12 PM
