71
1. MID REMOTE VALVE JOYSTICK
Front-loader exclusive joystick valve is attached and con-
trol lever is attached on right-front side of driver’s seat.
Loader will move up when pushed forward and move
down when pulled backward. Bucket will move up when
pushed to the left and move down when pushed to the
right. Joystick lever must be locked when driving while
loader is lifted. Otherwise it may cause accident.
The gear is shifted in four levels. When shifting the gears
depress the clutch fully.
2. MAIN GEAR SHIFT LEVER
FUNCTIONS
20R OPERATORS MANUAL (030712).indd 71 3/8/2012 4:04:13 PM
