72
3. 3PT POSITION CONTROL LEVER
It is used to keep the implement constantly at a certain
position. When the lift lamp is on, the implement cannot
be lowered with position control lever. A stopper is used
to x the position control lever in the “UP” position while
driving on a road.
•When lowering the implement, set the position control
lever, and the implement will go down to the set position.
The range gear is shifted in three levels(A-B-C). The
combination with the main gear provides 12 levels of
gear shifting.
When shifting the range gear, stop tractor and depress
clutch pedal fully.
4. RANGE SHIFT LEVER
FUNCTIONS
Conrm that no one or a foot is under the
implement before operating the system.
WARNING
[Otherwise]
There is a danger of injury
20R OPERATORS MANUAL (030712).indd 72 3/8/2012 4:04:13 PM
