66
FUNCTIONS
8) FUEL GAUGE
Indicates the quantity of fuel remaining in the tank. If the needle
is in the red zone, rell immediately.
9) WATER TEMP GAUGE
The needle indicates the temperature of the engine coolant
during running. If the needle is in the red zone, stop running
the engine and check for problems.
10) HEAD LAMP (HIGH BEAM)
Indicates the head lamps beam’s position.
It will come on when the head lamps are on Hi beam. On the
contrary, if the head lamps are in the low beam, this indicator
will not be lit.
20R OPERATORS MANUAL (030712).indd 66 3/8/2012 4:04:12 PM
