CHAPTER 6 HYDRAULIC SYSTEM 3015R(h)/3515R(h)/4015R(h)/F36R(h)/F42R(h) TRACTOR































)5217
6&9
F42W606A
(1) Knob, scv lever
(2) Lever A ass’y
 (3)Hexangebolt
(4) Shaft ass’y
(5) Snap ring(E)
(6) Bush
(7) Boss B ass’y
(8) Link(1) ass’y
(9) Cotter pin
(10) Plain washer
 (11)Hexangebolt
(12) Bracket ass’y
(13) Bracket, scv lever
 (14)Hexangebolt
(15) Bracket
(16) Cover relief
(17) Scv PTO 3sd
(18) Scv(2port)
(19) O-ring
(20) O-ring
(21) Stud bolt
(22) Spring washer
(23) Hex nut
(24) O-ring
(25) Joint(1/2)
(26) Joint arm(1/2)
(27) O-ring
(28) Elbow
COMPONENTS
F36R(h)/F42R(h)
