④ Display the model outline
Click [View] > [Show Model Outline]. The yellow outline of the object is then
highlighted.
⑤ Display of a steep overhang
Click [View] > [Show Steep Overhang]. If the angle of intersection between the
model surface and the horizontal line is within the range of the overhang threshold, the
surface has a steep overhang and is displayed in red in the software. The threshold
value for the overhang can be adjusted as required. By default the value is set to 45°.
3.2.5 Moving
Select the desired object and move it using one of the following two methods:
Method 1: Left click on the [Move] icon, hold down the left mouse button and
drag to move the position of the model in the XY direction. Hold down the Shift key and
left mouse button and drag to move the position of the model in the Z direction. The
distance and direction of movement are displayed.
Method 2: Click the [Move] button on the left, and then enter a value for the
distance. Click [Reset] to reset the distance values.
Note: After adjusting the position, you should click [Centre] and [On Platform] to
ensure that the models are in the print area and on the print platform. If a specific
position is required, click only [On Platform].
