Bridgeport Interact 2 - Page 91

Do
the
joystick
axis controls
operate correcdy?
Does the
control
display
read:
.DEFECT
ON*
_
MEASURING
SYSTEM'?
Does
the control
disPlaY
read
t
.CONTROL
_
ELECTRONICS
DEFECTIVE'
or
'PROGRAMME
MEMORY
DEFECTIVE'?
Does the
conuol
displaY
read,
.GROSS
POSITIONING
ERROR'?
Do
the
joysticks
controls
operate
correctly
in the
rapid mode?
Turn
to
the
next
page
Faulty encoder
or associated
cable
on the
indicated*
aris
Faulty
control unit
Axis
slide
tight
-
check
that
a,xis
is
free by
winding
ares
via
belts.
Feed drive card
correctly
adjusted
or
faulty
Neutral microswitch
on
rear of
joystick
incorrectly
adjusted
or
faulty
YES
NO
YES
YES
NO
YES
YES
Turn
to next
page
1
1-10
