5
Indicator Panel Description
1� Power indicator – When illuminated, indicates that the dispenser is on. When
blinking, indicates that the self-cleaning feature is operating.
2� Hot water indicator light – When illuminated, indicates that the dispenser is
heating water.
3� Cold water indicator light – When illuminated, indicates that the dispenser is
cooling water.
4� Bottle indicator light – When blinking slowly, indicates water bottle is empty
and needs to be refilled; when blinking quickly, indicates the filter is about to
expire; and when steadily illuminated, indicates the filter has expired.
Product Dimensions
Height Width Depth
41.4 in. (105.1 cm) 12.2 in. (31.1 cm) 15.6 in. (39.6 cm)
Operational Specifications
CAUTION: This unit dispenses water at temperatures that can cause severe burns. Avoid direct contact
with hot water. Keep children and pets away from unit while dispensing. Never allow children to
dispense hot water without proper and direct supervision. Unplug unit to prevent unsupervised
use by children.
Temperature Tank Capacity Flow Rate
Dispensing Cold Water
37–50 °F (3–10 °C) 1 g (3.6 L) 0.32 gpm (1.2 ipm)
Dispensing Hot Water
176–198 °F (80–92 °C) 0.24 g (1 L) 0.32 gpm (1.2 ipm)
Installation
1� Determine Installation Location
A� Place the dispenser upright, on a hard and level surface.
B� Ensure the dispenser is placed in a cool, shaded setting near a
grounded wall outlet.
NOTICE: Do NOT plug in the power cord until the entire installation
section is completed.
C� Position the back of the dispenser no closer than 20cm (8in) from a wall
and permit free airflow between the wall and water dispenser.
2� Install the Drip Tray and Grid
A� Unwrap the removable drip tray and grid (8) from the packaging
material. Attach the grid to the drip tray, then slide them into the dispenser until securely in place.
1 2 3 4
8
