Brivis 19 Evap AC IM
10. DISMANTLING
10.1 REMOVING THE FRONT AND REAR PADS
For general servicing, remove the front and back pads to access all components�
•
Loosen the 4 plastic thumbscrew knobs on the c ooler’s roof until the large front pad can be lifted up enough to
clear the bottom edge�
•
Swing the large front pad out at the top edge�
•
Remove the 2 thumbscrews above the small back pad completely�
•
Raise the roof until the small back pad has enough clearance at the top to be removed�
•
With the front and rear pad frames removed, the lter pads simply slide up and out of their frames.
10.2 REMOVING THE SIDE PADS
Remove the front and back pads as above, then:
•
Disconnect the 19mm clear hose supplying water to the roof distribution spreader at the tting in the cooler’s
base (squeeze clip then pull to release)�
•
Ensure that all thumb screws have been removed�
•
Remove the roof assembly�
•
Slide the lter pads up and out of their frames.
10.3 DISMANTLING THE FRAMEWORK
Complete all the steps above then:
•
From the front of the unit remove all four 10g screws securing the posts to the base caps� Note that the top
brackets are glued to the posts, and cannot be separated�
•
Lift up and remove the 4 PVC support posts, disengaging the pad’s restraining angle brackets�
•
Slide the side pad frames out from the formed brackets at the base of the frames�
•
Remove the side pad frames and external panel assemblies�
