• Power status LEDs are listed in Power supplies.
• Hardware specifications for the power supplies are listed in Power supplies.
• Redundant power supplies and power supply failure information is listed in About redundant power
supplies and power supply failure on page 36.
AC power supplies
AC power supplies shows a rear view of a device containing one AC power supply.
FIGURE 33 AC Power Supply
1 Power supply
2 Six cooling fans
DC power supplies
The DC power supply is shown in the diagram DC power supplies.
FIGURE 34 DC Power Supply
AC power supplies
Brocade NetIron CES 2000 Series and NetIron CER 2000 Series Hardware Installation Guide 35
53-1003823-01
