Required tools
You will need the following tool to perform this procedure:
• #2 Phillips-head screwdriver
The following procedures are required when removing an AC power supplies from a device.
1. Unplug the power supply from the power source.
2. Disconnect the power cord from the power supply.
3. Unscrew the two power supply locking screws located at the top left and bottom right hand corner of
the power supply.
FIGURE 49 Power supply screw location
1 Power supply locking screws
4. Pull the power supply outward once the screws have been unscrewed. This will disconnect the
power supply from the backplane.
Required tools
82 Brocade NetIron CES 2000 Series and NetIron CER 2000 Series Hardware Installation Guide
53-1003823-01
