98
BAS-311E.311EL.326E.326EL
Chapter 7
Test
Press the
TEST switch.
Step on the start
foot switch.
Step on the
presser plate
lifter switch.
Release the
presser plate
lifter switch.
NO
YES
Is the TEST lamp lit?
NO
YES
Is the material fed
during sewing stitch
by stitch?
NO
YES
Does the feeding operation
get faster?
NO
YES
Does the presser
plate movement match the
floppy disk data?
NO
YES
Does
the presser plate
return to the sewing start
position without
error?
OFF
OFF
OFF
OFF
#9
#10
#11
#12
Input sewing data
and shift to the
sewing start
position.
