99
BAS-311E.311EL.326E.326EL
Chapter 7
Sewing
operation
Press the TEST
switch to turn off
the TEST lamp.
Step on the
start foot
switch.
YES
NO
Does an error code
appear after the machine
starts?
NO
YES
Does the presser plate
move stitch by stitch to
sew the material?
YES
NO
Machine does not
start and an error code
appears?
NO
YES
Are thread trimmer
and thread wiper
activated?
NO
YES
Does the machine
stop with the needle at the
upper position?
NO
YES
Does the
machine return to the
sewing start state according
to the floppy disk
data?
OFF
OFF
OFF
OFF
#13
#15
OFF
#14
#16
#17
OFF
#18
Input sewing data
and shift to the
sewing start
position.
