Brother DCP-8080DN User Guide

Troubleshooting and routine maintenance
105
C
e Put the toner cartridge firmly into the
new drum unit until you hear it lock into
place. If you put the cartridge in
properly, the blue lock lever will lift
automatically.
Note
Make sure that you put in the toner
cartridge properly or it may separate from
the drum unit.
f Clean the corona wire of the drum unit
by gently sliding the blue tab from right
to left and left to right several times.
Note
Be sure to return the blue tab to the home
position (a) (1). If you do not, printed
pages may have a vertical stripe.
g Put the new drum unit and toner
cartridge assembly in the machine.
Do not close the front cover.
h Press Clear/Back.
Replace Drum?
a 1.Yes
b 2.No
Select ab or OK
To confirm you are installing a new
drum, press 1.
i When the LCD shows Accepted, close
the front cover.
1

Brother DCP-8080DN Specifications

General

Zoom capability	25 - 400%
Maximum print size	-
Standard input capacity	250 sheets
Color scanning	Yes
Enhanced scan resolution	19.200 x 19.200 DPI
Print technology	Laser
Time to first page (black, normal)	8.5 s
Standard interfaces	USB 2.0/RJ-45
Built-in processor	NEC VR5500
Internal memory	64 MB
Compatible operating systems	Windows/Mac OS
Type	Digital copier
Sustainability certificates	ENERGY STAR
Power consumption (standby)	16 W
Power consumption (typical)	680 W
Operating relative humidity (H-H)	20 - 80 %
Maximum operating temperature range (T-T)	50 - 91 °C
Pallet dimensions (W x D x H)	627.38 x 566.42 x 574.04 mm
Processor model	VR5500
Processor family	NEC

Weight and Dimensions

Weight	18098 g
Package weight	22000 g
Maximum dimensions (W x D x H)	530.86 x 449.58 x 474.98 mm
