1-2 Confidential
No. Name Description
(1) Control panel
Use the keys to operate the machine. The liquid crystal display
(LCD) shows the machine operation status.
(2) Ink cartridge cover Open to replace ink cartridges.
(3) Paper tray
Load paper here. Paper will be fed into the machine, sheet by
sheet.
(4)
Media slots for PhotoCapture
Center
Insert a memory card here.
(5) PictBridge jack Connect a digital camera to this jack using the USB cable.
(6) Scanner cover (Scanner unit) Open to remove jammed paper.
(7)
ADF & document cover ASSY
ADF: Load documents (originals) here. Documents will be fed
into the machine, page by page.
Document cover: Open to place the document (original) on the
scanner glass.
(8) USB interface connector Connect the USB cable here.
(9)
LAN cable connector*
Connect the LAN cable here.
(10) Jam clear cover Open to remove paper jammed inside the machine.
*For wired LAN-enabled models
To Next Page
