3-2 Confidential
3.2 MECHANICAL COMPONENTS
This machine consists of the following mechanisms and uses motors (four in models with ADF and
three in models without ADF), two encoders, various sensors, and thermistors.
Scanner Mechanism
(Right)
(Left)
(3_01)
Document path for ADF scanning
Document for flat-bed scanning
Printing Mechanism
Ink supply and ink jet mechanism, head maintenance mechanism, and carriage drive mechanism.
(Front)
(Rear)
- Carriage drive mechanism
- Ink supply and ink jet mechanism
- Head maintenance mechanism
(3_01_1)
To Next Page
