7.2 IF YOU REPLACE THE HEAD/CARRIAGE UNIT
OR ENGINE UNIT
[ 1 ] Update the head property information stored in the EEPROM on the main PCB
(1) Make sure that the machine's power cord is unplugged from an electrical outlet.
If the machine is connected to a PC, unplug the USB cable.
(2) Switch on the PC.
(3) Plug the machine's power cord into an electrical outlet.
(4) Press the Menu and Black Start (Mono Start) keys. Next press the
key four times to make
the machine enter the maintenance mode.
The machine displays "
" on the LCD, indicating that it is placed in the
initial stage of the maintenance mode, a mode in which the machine is ready to accept entry
from the keys.
(5) Connect the machine to the PC using a USB cable.
(6) On the PC, run the ID/head property setup utility (brusbsn.exe) in the folder created. The
following window appears.
(7) On the model menu, click BH7.
