Brother DCP130C - Outline

1-1 Confidential
1.1 OUTLINE
 Models with ADF
Front view
(1) Control panel
(3) Paper tray
(6) Scanner cover
(Scanner unit)
(2) Ink cartridge cover
(4) Media slots for
PhotoCapture Center
(front_view_stepup)
(7) ADF & document
cover ASSY
(5) PictBridge jack
Back view
(10) Jam clear cover
(8) USB interface connector
(back_view_stepup)
(9) LAN cable connector*
*For wired LAN-enabled models
