2. OVERVIEW
2.1 Cross-section Drawing
Fig. 1-1
Laser unit
Plate Pick-up roller Separation Pad
Paper feed
actuator L/R
Separation roller
Paper printing
position actuator
Back cover
Transfer roller
Exposure drum
Corona wire
Fuser unit
Pressure roller
Eject actuatorEject roller
Supply roller
Developer roller
Heat roller
Tray cover
