Brother HL-1112 - Back Cover

2-9
Confidential
7.2 Back cover
(1) Remove the two taptite bind B M4x12 screws.
(2) Release the two hooks at the top of the back cover while lifting it.
(3) Slide the back cover downward to remove the two bosses at the bottom.
Fig. 2-4
Back cover
Bosses
Hooks
Taptite bind B
M4x12
