7. DISASSEMBLY PROCEDURE
7.1 Preparation
Disconnecting Cable and Removing Accessories
Prior to proceeding with the disassembly procedure,
(1) Disconnect the following:
• USB cable (if connected)
(2) Remove the following:
• Toner cartridge and drum unit
Fig. 2-3
USB cable
Toner cartridge
and drum unit
